B160C
PRODUCT FEATURES
- The whole machine features advanced performance, effective matching of the power transmission system, and high working efficiency
- With the fuel tank positioned on the left side of the machine body, the ultra-large rear space makes the care and maintenance of steering and brake systems easy.
- The front arrangement of the working cylinder improves the load- carrying performance, delivering
Previous
Next
SPECIFICATION
Operating weight
17000 kg
Engine power
131 kW (176 hp / 178 ps) @ 1850 rpm
blade capacity
4.5 m³
Max travel speed, fwd
10.6 km/h
Max travel speed, rev
13.6 km/h
system voltage
24 V
Referenced Shoe width
510 mm
Footing numbers per side
37
Pressure
14 MPa
Fuel tank
350 L
Motor oil
24 L
Transport length
5180 mm
Transport height
3200 mm
blade width
1130 mm
Ancho de la hoja
3422 mm
