915E
Product Features
– Proven negative flow hydraulics have optimize the main control valve, improved the speed of front end cylinders, while cutting down the hydraulic system’s damper loss, leading to much better working efficiency. The pilot valves matching with the main control valve offer precise control.
– The 915E model is powered by the latest generation, low emission Cummins engine, with enhanced power output, improved breakout force and faster cycle times.
– The LiuGong E series excavator features 6 selectable working modes that optimize performance and fuel consumption to your specific conditions
– Ergonomically designed cab for LiuGong E series excavator, with great visibility, expansive leg room, new multi-function LCD monitor, automatic air conditioner, large storage space, provide most comfortable working environment
SPECIFICATION
Operating weight
13800 kg
Engine power
81 kW @ 2200 rpm
Bucket capacity
0.36 / 0.73 m³
Maximum travel speed (High)
5.1 km/h
Maximum travel speed (Low)
3.3 km/h
Maximum swing speed
12.94 rpm
Arm breakout force
64.9 kN
Arm breakout force Power boost
70 kN
Bucket breakout force
89.8 kN
Bucket breakout force Power boost
96.9 kN
Shipping length
7750 mm
Shipping width
2490 mm
Shipping height
2930 mm
Track shoe width (std)
500 mm
Boom
4600 mm
Arm
2500 / 2100 mm
Digging reach
8300 / 7924 mm
Digging reach on ground
8170 / 7784 mm
Digging depth
5500 / 5086 mm
Vertical wall digging depth
4770 / 4428 mm
Cutting height
8760 / 8480 mm
Dumping height
6310 / 6024 mm
Minimum front swing radius
2470 / 2400 mm
Model
Cummins
Emission
EPA Tier 2
System maximum flow
2×132 L/min (2×35 gal/min)
System pressure
34.3 MPa
Operating weight
13800 kg
Standard bucket size
0,73 m³
Bucket sizes
0,6 – 0,73 m3
Gross power
117 hp (86 kW) @ 2.200 rpm
Net power
109 hp (80,2 kW) @ 2.200 rpm
Swing speed
12,94 rpm
Maximum travel speed
5,1 km/h
Arm digging force (power boost)
70 kN
Bucket digging force (power boost)
96,9 kN
Main pumps total flow
2×132 L/min
Engine
Cummins QSF3.8
Emission regulation
Nivel 3
Relief pressure, main
34,3 MPa
Boom length
4.600 mm
Arm length
2.500 mm
Max. digging reach
8.300 mm
Max. digging reach on ground
8.170 mm
Max. digging depth
5.500 mm
Max. digging depth, 2.44 m (8′) level
5.250 mm
Max. cutting height
8.760 mm
Max. dumping height
6.310 mm
Min. front swing radius
2.470 mm
Transport height
2.900 mm
