9035E
PRODUCT FEATURES
- Zero tail swing
- Ergonomically designed cab and ergonomic placement of instruments
- Open ROPS available
- Hammer/Shear hydraulics and piping
Previous
Next
SPECIFICATION
Operating weight
3.860 – 3.980 kg
Standard bucket size
0,11 m³
Bucket sizes
0,6 – 0,11 m3
Gross power
29,8 hp (22,2 kW) @ 2.400 rpm
Net power
28,4 hp (21,2 kW) @ 2.400 rpm
Swing speed
10 rpm
Maximum travel speed
4,6 km/h
Arm digging force (power boost)
20 kN
Bucket digging force (power boost)
30 kN
Main pumps total flow
92,4 L/min
Engine
Yanmar 3TNV88 – BPLYB
Emission regulation
Tier 3
Relief pressure, main
24,5 MPa
Boom length
2.450 mm
Arm length
1.320 mm
